Specially designed for hospitals, stretcher movement and smooth patient transportation, our hospital elevators provide spacious cabins, reliable leveling, quiet operation and maximum comfort.
| Specification | 15 P | 17 P | 20 P | 26 P |
|---|---|---|---|---|
| Car Weight Load / Weight in KG | 884 | 1020 | 1360 | 1768 |
| Car Width (A) Car Inside Width | 1800 | 1900 | 2000 | 2400 |
| Car Depth (B) Car Inside Depth | 2400 | 2800 | 2800 | 3000 |
| Entrance Width (C) Door / Entrance | 1100 | 1150 | 1200 | 1500 |
| Entrance Depth (D) Well Entrance | 2000 | 2400 | 2400 | 2400 |
| Pit (E) Minimum Pit | 800 | 900 | 1000 | 1000 |
| Shaft Width (F) Well Width | 1800 | 1900 | 2000 | 2400 |
| Shaft Depth (G) Well Depth | 2400 | 2800 | 2800 | 3000 |
| Over Head (H) O.H. Requirement | 2000 | 2400 | 2400 | 2400 |
Hospital elevators are designed for smooth, silent and reliable transportation of patients on wheelchairs and stretchers. They provide sufficient space for doctors, nurses and emergency equipment while ensuring comfortable movement without unnecessary jerks or shocks.
